UV/VIS Spectro photo Meter (Double Beam)

Make

ASICO

Model

ASICO-SPM-27A

Optical System

Double Beam, 1200lines/mm grating

Wavelenght Range

190 nm 1100 nm

Spactral Bandwidth

1 nm

Wavelength Accuracy

0.5nm

Wavelength Repeatability

0.2nm

Wavelength Resolution

0.1 nm

Wavelength Settings

Auto, Resolution 0.1nm

Scanning Speed

Fast, Mid, Slow

Photometric Accuracy

0.002 A (00.5A), 0.003A (0.51A), 0.3%T (0100%T)

Photometric Repeatability

0.001 A (00.5A), 0.002A (0.51A), 0.2%T (0100%T)

Photometric Range

0200%T, -44A, 09999C

Photometric Mode

A.T.C

Stray Light

0.05%T(220/360nm)

Stability

0.001A/h (500nm,0A)

Baseline Flatness

0.001A

Noise

0.2%T/3min (250/500nm,0%T); 0.5%T/3min (250/500nm,100%T)

Light Source

Deuterium & Tungsten Lamp

Drift

<=+/0.0004A bs/h

Cell Holder

2 Cell Holder

Keyboard

30-key Alphanumeric Membrance Keypad

Detector

Silicon Photodiode

Interface

USB Port & Parallel Port (Printer)

Power

AC 220V/50Hz

Dimension

545x468x245mm

Net Weight

18kg

Accessories

Glass Cell (4nos.), Quartz Cell (2nos.), Fuse (2nos.), Instrument. Cover (1no.), Software CD (1no.), USB cable (1no.), Operation Manual (1no.)
